1、 Product Introduction

The ZT140TA-NN-45-1535 photoelectric turntable consists of an uncooled infrared thermal imager, a 30x continuous zoom visible light camera, a laser rangefinder, a two axis servo stabilization platform, and an image tracker. It has the characteristics of light weight, high stability and accuracy, and high integration, and can be applied to unmanned vehicles and ships to complete tasks such as day and night reconnaissance, monitoring, and target positioning of target areas.

The photoelectric turntable uses non cooled infrared thermal imagers and visible light cameras to detect, recognize, and track targets throughout the day, and outputs real-time infrared and visible light videos for task execution personnel to view.

2、 Physical pictures

3、 Product features

a) Equipped with self inspection and fault reporting functions;

b) Capable of detecting long wave infrared and visible light bands, capable of outputting infrared and visible light images;

c) Visible light has optical zoom, autofocus, manual focusing, and low illumination functions;

d) Infrared has 1-4 times electronic amplification and six color palette switching functions;

e) Equipped with laser ranging function;

f) Having the ability to move in both azimuth and elevation degrees of freedom;

g) Equipped with various working modes such as automatic search, manual search, follow-up, attitude stability, and tracking;

h) In manual search mode, it has the function of receiving control station instructions and completing turntable operations;

i) Capable of isolating carrier disturbances and stabilizing aiming lines;

j) Equipped with lock/unlock target function, and the output image of the turntable after locking the target is an image with a tracking box;

k) Equipped with automatic target tracking function, capable of automatically tracking targets, and capable of resisting natural interference;

l) Equipped with memory tracking function, the target can be captured again in a short period of time after a brief loss;

m) Capable of adjusting the size of the wave gate;

n) Equipped with tracking point switching function;

o) It can communicate with the control station in both directions through RS422/100Mbps network, and output information such as infrared images, visible light images, system operation status, camera operation status, and optical axis position;

p) Equipped with HD-SDI/synchronous 422/100Mbps network/HDMI multi-channel video output interface;

q) Capable of taking photos and recording videos;

4、 Mount platform

Unmanned vehicles, unmanned ships, manned vehicles, manned ships, etc.
