1、 Product Introduction

The ZT007T two axis 50Km detection and tracking system is composed of high-performance 640 × 512 refrigeration type continuous zoom medium wave infrared thermal imager, large area array 1024 × Composed of 768 non cooled continuous zoom long wave infrared thermal imager, 50x continuous zoom visible light camera, two axis servo stable platform, and image tracker. It has the characteristics of high stability, accuracy, and integration, and can be applied to unmanned vehicles, armored vehicles, watchtowers, etc., to complete tasks such as day and night reconnaissance and monitoring of target areas.

The photoelectric turret uses non cooled infrared thermal imagers and visible light cameras to detect, recognize, and track ground targets throughout the day, and outputs real-time infrared and visible light videos for task execution personnel to view.

Photoelectric turrets are mainly used in scenarios such as air detection, ground detection, border and coastal defense, monitoring of high points, and border outposts.

2、 Physical image

3、 Product features

a) Equipped with self inspection and fault reporting functions;

b) Capable of detecting infrared and visible light bands, capable of outputting infrared and visible light images;

c) Visible light has optical zoom, autofocus, manual focusing, and low illumination functions;

d) The medium wave refrigeration detection component has an electric zoom function;

e) The long wave non cooled large area array infrared camera has dual field of view switching function and electric focusing function;

f) Infrared has 1-4 times electronic amplification and six color palette switching functions;

g) Each band detection subsystem has an external synchronization function, which can ensure that each band is synchronized under the control of external synchronization signals

The exposure time of the subsystem is at the same time;

h) Having the ability to move in both azimuth and elevation degrees of freedom;

i) Equipped with various working modes such as automatic search, manual search, follow-up, automatic tracking, and bookmarking;

j) In manual search mode, it has the function of receiving control station instructions and completing tower transfer operations;

k) Capable of isolating carrier disturbances and stabilizing aiming lines;

l) Equipped with lock/unlock target function, and the output image of the turret after locking the target is an image with a tracking box;

m) Equipped with automatic target tracking function, capable of automatically tracking targets, and capable of resisting natural interference;

n) Equipped with memory tracking function, the target can be captured again in a short period of time after a brief loss;

o) Capable of adjusting the size of the wave gate;

p) Equipped with tracking point switching function;

q) Equipped with automatic closed-loop motion pointing function according to the planned path;

r) Capable of outputting target information and video output

s) Having infrared raw images, target characteristics, and target flight characteristics (including target orientation and pitch angle)

Storage function for tracking images of angular velocity, infrared, and visible light

t) It can communicate with the control station in both directions through RS422/100Mbps network, and output information such as infrared images, visible light images, system operation status, camera operation status, and optical axis position;

u) Equipped with network/HD-SDI video output interface;

v) Capable of taking photos and recording videos;

w) Universal design of external mechanical interfaces for each subsystem to meet the installation requirements of other optical detection systems.

4、 Carrying platform

Ground fixed area, vehicle mounted, ship mounted, etc.
